Parent Layer: Schedule F Transportation

Name: Road Classification

Display Field: ROAD_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Published to </SPAN><SPAN STYLE="font-weight:bold;">Service_SouthgateOfficialPlan</SPAN><SPAN>, Schedule F.</SPAN></P><P><SPAN /></P><P><SPAN /></P></DIV></DIV></DIV>

Service Item Id: e30ff60a7cf04a47b49ee67f72560a7b

Copyright Text: Grey County Carolyn B

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8996200.137095394
YMin: 5462339.556312186
XMax: -8945666.61827561
YMax: 5499371.793922869
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: RoadType
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Highway
  Label: Provincial Highway
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [28, 28, 28, 255]
  Width: 3
• Value: Highway Connecting Link
  Label: Provincial Highway Connecting Link
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [28, 28, 28, 255]
  Width: 3
• Value: Arterial
  Label: County Arterial
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [250, 52, 17, 255]
  Width: 4
• Value: Collector
  Label: County Collector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [168, 0, 230, 255]
  Width: 4
• Value: Local
  Label: County Local
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 170, 0, 255]
  Width: 4
• Value: <Null>
  Label: Municipal Local
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
• Value: Potential
  Label: Potential Planned County Arterial
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [247, 111, 238, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ROAD_LENGT ( type: esriFieldTypeDouble, alias: ROAD_LENGT )
• LANE_COUNT ( type: esriFieldTypeSmallInteger, alias: LANE_COUNT )
• SPEED_LIMI ( type: esriFieldTypeSmallInteger, alias: SPEED_LIMI )
• ROAD_NAME ( type: esriFieldTypeString, alias: ROAD_NAME, length: 50 )
• ALTERNATE_ ( type: esriFieldTypeString, alias: ALTERNATE_, length: 50 )
• ROAD_JURIS ( type: esriFieldTypeString, alias: ROAD_JURIS, length: 50 )
• STREET_CLA ( type: esriFieldTypeSmallInteger, alias: STREET_CLA )
• STREET_NAM ( type: esriFieldTypeString, alias: STREET_NAM, length: 50 )
• STREET_TYP ( type: esriFieldTypeString, alias: STREET_TYP, length: 5 )
• STREET_DIR ( type: esriFieldTypeString, alias: STREET_DIR, length: 2 )
• L_F_ADD ( type: esriFieldTypeInteger, alias: L_F_ADD )
• L_T_ADD ( type: esriFieldTypeInteger, alias: L_T_ADD )
• R_F_ADD ( type: esriFieldTypeInteger, alias: R_F_ADD )
• R_T_ADD ( type: esriFieldTypeInteger, alias: R_T_ADD )
• LOCATION ( type: esriFieldTypeString, alias: LOCATION, length: 20 )
• VERIFY ( type: esriFieldTypeSmallInteger, alias: VERIFY )
• VERIFY_COM ( type: esriFieldTypeString, alias: VERIFY_COM, length: 50 )
• DATE_ADD ( type: esriFieldTypeDate, alias: DATE_ADD, length: 8 )
• UNOFFICIAL ( type: esriFieldTypeString, alias: UNOFFICIAL, length: 50 )
• STATUS ( type: esriFieldTypeString, alias: STATUS, length: 50 )
• HWY_NUM ( type: esriFieldTypeString, alias: HWY_NUM, length: 5 )
• GREYRD_NUM ( type: esriFieldTypeString, alias: GREYRD_NUM, length: 5 )
• CLOSE_DETR ( type: esriFieldTypeString, alias: CLOSURE DETOURS, length: 20 )
• RouteID ( type: esriFieldTypeString, alias: RouteID, length: 40 )
• RoadID ( type: esriFieldTypeSmallInteger, alias: RoadID )
• EDIT_DATE ( type: esriFieldTypeDate, alias: EDIT_DATE, length: 8 )
• RoadType ( type: esriFieldTypeString, alias: RoadType, length: 50 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
